Access Control

Dimension 1

239 mm × 116.5 mm × 33 mm (9.4" × 4.6" × 1.3")
118 mm × 118 mm × 20 mm (4.6'' × 4.6'' × 0.7'')
205 mm × 76.5 mm × 37 mm (8.07" × 3.01" × 1.46")
398 mm × 474 mm × 100 mm (15.7" × 18.7" × 3.9")
373 mm × 345 mm × 98 mm (14.7" × 13.6" × 3.6")
62 mm × 132 mm × 44 mm (2.44" × 5.20" × 1.73")

Weight 1

0.5 kg (1.1 lb)

Two-Way Audio

Support

Power Supply

12 VDC, 2 A
12 VDC, 2 A (power adapter not included)
12 VDC/1 A
1 A (12 VDC to 24 VDC)
100 ~ 240 VAC
12 VDC ± 10%

Working Temperature

-30 ℃ to 60 ℃ (-22 °F to 140 °F)
-10 °C to 50 °C (14 °F to 122 °F)
-10 °C to +55 °C (14 °F to +131 °F)
-40 °C to +70 °C (-40 °F to +158 °F)
-20 °C to 65 °C (-4 °F to 149 °F)
-20 °C to 65 °C (-4 °F to 149 °F)
-40 °C to 70 °C (-40 °F to 158 °F)

Working Humidity

10 to 90％ (No condensing)
0 to 90% (No condensing)
10% to 90% (no condensing)
10% to 90% (no condensing)
10% to 90% (no condensing)
10% to 90% (no condensing)

Screen Size

7 inch
4.3 inch
2.4-inch

Operation Method

Capacitive touch screen

Type dis

LCD
IPS
LCD-TFT display screen

Lens

2
1

Resolution

2 MP
320 × 240

FOV vid

HFOV = 46°; VFOV = 87°
HFOV = 110°; VFOV = 81°; DFOV = 122°

Audio Quality

Noise suppression and echo cancellation

Wired Network

Support
TCP/IP, 10/100Mbps, self-adaptive
10 M/100 M self-adaptive

Network Interface inter

1 RJ-45, 10/100/1000 M self-adaptive
1 RJ-45, 10/100/1000 M self-adaptive
1
TCP/IP

Lock Control

1

Exit Button

1

Door Contact Input

1

TAMPER

1

Alarm Input inter

2
1
4

Alarm Output inter

1
2

RS-485

1 RS-485 (Half duplex, HIKVISION)
1 RS-485 (Half duplex, HIKVISION)
1

Wiegand inter

1 Wiegand(Hik 26bit,Hik 34bit)
1 Wiegand(Hik 26bit,Hik 34bit)
1
1 (output)

USB inter

2
1

Card Type

M1 card
M1 card;DESfire card

Card Reading Frequency

13.56 MHz

Installation

Surface mounting
Surface, optional base stand
Surface mounting

Language gen

English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil)
English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil)
English, Vietnamese, Brazilian Portuguese, Spanish, French, Italian, Arabic, Thai, Turkish, Indonesian, and Ukrainian
Arabic, English, French, Indonesian, Italian, Portuguese (Brazil), Russian, Spanish (Europe), Thai, Ukrainian, Vietnamese, German, Polish, Hungarian, Czech, Romanian, Bulgarian, Croatian, Serbian, Greek, Slovak, Portuguese, Dutch, and Turkish

Platform

Hik-ProConnect and HikCentral Professional

QR Code Recognition

Support

Face Anti-Spoofing

Support

Power Consumption 1

≤ 10 W
≤12 W
≤ 4 w (without load) ≤ 50 w (with load)
With load: ≤ 50 w Without load: ≤ 4 w
≤ 1.6 W

Audio Output

1 loudspeaker, 1 buzzer

Wi-Fi

Support

Card Capacity

3000
100,000

Fingerprint Capacity

3000
10,000

Event Capacity

100,000
300,000

Card Reading Distance

0 to 4.5 cm
0 ~ 3 cm

Card Reading Duration

＜ 1 s

Fingerprint Module

Optical fingerprint module
Capacitive fingerprint recognition

Fingerprint Comparing Mode

1:1 and 1:N
1:1/1:N

Fingerprint Recognition Duration

＜ 1 s

Indicator

Power/status (red/green)

Color

Black (included), gold (optional), silver (optional), white (optional)

Operating System

Linux

Video Compression Standard

H.264 and H.265

Video Standard

PAL (Default) and NTSC

SD Card Slot

1

Protective Level

IK09, IP65

Video Intercom

Support

Hik-Connect

Support

Buzzer

Support
